For Immediate Release
12V, 7A (84W) High Performance
16th Brick DC-DC Converter
Atkinson, NH – May 1st, 2010 - Semiconductor Circuits, Inc. introduces
the CPT7B48 “Cool Power Technologies” 12V, 7A 16th brick DC-DC
converter. This open frame module provides a full 84W of 12V power
@ 55C & 200lfm of airflow – ideal for distributed power architecture
applications or as a fully regulated intermediate bus converter. This
module is compliant with DOSA footprint and interface standards. It
has a wide input voltage range of 36 to 75VDC & provides 2250VDC
input to output isolation.
The CPT7B48 is a high efficiency module with efficiencies exceeding 93% from ½ load through
full load. It meets EN 60950 basic insulation requirements and is UL94 V-0 flammability rated.
The module complies with all of the typical industry requirements including no load operation,
100V/100mS input voltage transient and pre-biased load startup.
Other features include: fixed-frequency operation, auto-restart OVP, OCP & OTP protections,
UVLO with 2V hysteresis, remote sense and +10/-20% output voltage trim using industry
standard equations. Remote ON/OFF is standard with positive or negative logic options
available.
The module features a standard 16th brick pinout and dimensions of 1.3” L x 0.9” W (22.9mm x
33mm.) It has a maximum height of 9.5mm (0.375”) which accommodates tight card spacing with
minimal airflow blockage of downstream components.
A product brief and technical datasheet is available at www.dcdc.com & sample quantities can
be ordered directly from stock via the website. Please contact sales@dcdc.com or call 1-888-
GET-DCDC (1-888-438-3232) toll free for OEM pricing and availability. We also welcome quickturn
modifications and custom configurations to meet our customer’s particular requirements.
Semiconductor Circuits, Inc. has been designing and manufacturing AC/DC & DC-DC modules
for over 40 years (founded in 1966.) Module applications include: industrial, test,
telecom/communications, networking, data-processing, railway, military, medical and
aerospace. Please visit our website at www.dcdc.com for more information.
