New DC/DC Converters

Consult factory for *RoHS converter model availability and lead-time.

Model Number Input Vdc Output Vdc Max Current Cat. Pages & Technical Ref. Notes RoHS
SC60B18-330-18 9-36V 18V 3.3A 60 Watt, Ultra Wide Input (9-36Vdc)(18-76Vdc), Open-frame, 1/2 bricks *RoHS
SC60B14-250-18 9-36V 24V 2.50A 60 Watt, Ultra Wide Input (9-36Vdc)(18-76Vdc), Open-frame, 1/2 bricks *RoHS
SC60B13-400-48 18-76V 15V 4.0A 60 Watt, Ultra Wide Input (9-36Vdc)(18-76Vdc), Open-frame, 1/2 bricks *RoHS
SC60B18-330-48 18-76V 18V 3.3A SC60B18-330-48 (TRN) 60 Watt, Ultra Wide Input (9-36Vdc)(18-76Vdc), Open-frame, 1/2 bricks *RoHS
SC60B14-250-48 18-76V 24V 2.50A SC60B14-250-48 (TRN) 60 Watt, Ultra Wide Input (9-36Vdc)(18-76Vdc), Open-frame, 1/2 bricks *RoHS
SC60B23-400-48 18-76V +/-15V +/-2.0A 60 Watt, Ultra Wide Input (9-36Vdc)(18-76Vdc), Open-frame, 1/2 bricks *RoHS
SC125A17-2500-24 18-36V 3.3V 25A 125 Watt DC/DC 1/2 brick converters *RoHS
SC125A11-2000-24 18-36V 5.0V 20A 125 Watt DC/DC 1/2 brick converters *RoHS
SC125A12-1000-24 18-36V 12.0V 10A 125 Watt DC/DC 1/2 brick converters *RoHS
SC125A17-3000-48 36-76V 3.3V 30A SC125A17-3000-48 (TRN)125 Watt DC/DC 1/2 brick converters *RoHS
SC125A11-2500-48 36-76V 5.0V 25A SC125A11-2500-48 (TRN) 125 Watt DC/DC 1/2 brick converters *RoHS
SC125A12-1000-48 36-76V 12.0V 10A 125 Watt DC/DC 1/2 brick converters *RoHS
SC10N1X2-3V3 3.0-3.6V 1.2V 10A SC10N1X2-3V3 (TRN) Non-isolated POL, SIP, 10Amp DC/DC Converter *RoHS
SC10N3X3-5V 4.5-5.5V 3.3V 10A SC10N3X3-5V (TRN) Non-isolated POL, SIP, 10Amp DC/DC Converter *RoHS
SC10N3X3-12V 10.8-13.2V 3.3V 10A SC10N3X3-12V (TRN) Non-isolated POL, SIP, 10Amp DC/DC Converter *RoHS
SC10N5X0-12V 10.8-13.2V 5.0V 10A SC10N5X0-12V (TRN) Non-isolated POL, SIP, 10Amp DC/DC Converter *RoHS
SC75A11-1500-48 18-75V 5.0V 15A SC75A11-1500-48 (TRN) 75 Watt DC/DC 1/2 brick converter with Ultra Wide Input Range *RoHS
SC75A12-625-48 18-75V 12V 6.25A SC75A12-625-48 (TRN) 75 Watt DC/DC 1/2 brick converter with Ultra Wide Input Range *RoHS
SC75A13-500-48 18-75V 15V 5.0A SC75A13-500-48 (TRN) 75 Watt DC/DC 1/2 brick converter with Ultra Wide Input Range *RoHS
SC75A14-300-48 18-75V 24V 3.0A SC75A14-300-48 (TRN) 75 Watt DC/DC 1/2 brick converter with Ultra Wide Input Range *RoHS
TRA Series Many options Many options Many options DC/DC Converters designed specifically for the Transportation Industry *RoHS
Half-bricks Many options Many options Many options *RoHS

All converters manufactured by Semiconductor Circuits, Inc. are backed by over 40 years of field proven value. You can count on us to provide you with the best possible DC/DC solution for your application, because we listen to your requirements and base our recommendations on your specific needs. Technical support is readily available; we are here to assist you.
